LE LIGHTOLUX BRAND

INPUT PARAMETERS:-

POWER CONSUMPTION – 100W (+/-5%)

INPUT VOLTAGE RANGE – 100-300 AC

INPUT FREQUENCY – 47-63Hz

POWER FACTOR / THD - >0.95 / <10%

POWER EFFICIENCY – 89%

 LED DRIVER:-

LED DRIVER TYPE – ISOLATED CONSTANT CURRENT DRIVER – BIS APPROVED

VOLTAGE / OUTPUT CURRENT – 36V DC/ 2500MA MAX

DIELECTRIC STRENGTH – 3KV ISOLATION

INPUT – INRUSH CURRENT, LIMITED, SURGE, PROTECTION

OUTPUT – SHORT CIRCLE, OPEN LED, OVER VOLTAGE, OVER LOAD

LED:-

LED TYPE & MAKE – 1W, 6V, 3030 SMD, CREE / SAMSUNG / OSRAM

NO. OF LEDS – 120NOS

LED PCB THOCKNESS – 1.6MM MCPCB, 2W/MK

LED EFFICACY - > 140LM / W

LED CCT – 5500-6500K

CRI - .80 ( 90+ CRI CAN PROVIDE ON DEMAND)

LED BEAM ANGLE -  120 DEGREE

LUMINARY:-

LIGHT COLOUR – COOL WHITE

LAMP BEAM ANGLE – 120 DEGREE

LUMINARY EFFICACY - >110 LM / WATT

EXTERNAL SURGE CAPABILITY – 10KV

WORKING ENVIROMENT - -40 DEGREE C 70 DEGREE  C

-                                       HUMIDITY -95%RH

STORAGE TEMPERATURE - -40 DEGREE C 70 DEGREE

IP RATING – IP65

IK RATING – 07

RATED LAMP LIFE ( AVERAGE ) - >50,000 HRS

LAMP BODY – DIE CASTED ALUMINIUM ALLOY

LUMINAIRE COVER – ANTI UV TOUGHENED GLASS

SECONDARY OPTICAL LENSES – AS PER SPECIFIC REQUIREMENT

CERTIFICATIONS BY NABL ACCREDITED LAB – LM79, IP65, IK07, 4KV SURGE ( ON-BOARD )
